Execute workflows in native code with the Python C API

txtai currently has two main methods of execution: Python or via a HTTP API. There are API bindings for JavaScript, Java, Rust and Go.

This article presents a way to run txtai as part of a native executable with the Python C API. We'll run an example in C and even call txtai from assembly code!

Before diving into this article, it's important to emphasize that connecting to txtai via the HTTP API has a number of major advantages. This includes decoupling from Python, the ability to offload txtai to a different machine and scaling with cloud compute. With that being said, this article demonstrates an additional way to integrate txtai along with providing an informative and perhaps academic programming exercise.

Install dependencies

Install txtai and all dependencies.

# Install txtai
pip install txtai[pipeline] sacremoses

# Remove tensorflow as it's not used and prints noisy log messages
!pip uninstall -y tensorflow

# Install python3.7-dev and nasm
!apt-get install python3.7-dev nasm

Workflow configuration

This configuration builds a workflow to translate input text to French. More information on workflows can be found in txtai's documentation.

summary:
  path: sshleifer/distilbart-cnn-12-6

textractor:
  join: true
  lines: false
  minlength: 100
  paragraphs: true
  sentences: false
  tika: false

translation:

workflow:
  summary:
    tasks:
    - action: textractor
      task: url
    - action: summary

  translate:
    tasks:
    - action: translation
      args:
      - fr

Python C API

Next we'll build an interface to txtai workflows with the Python C API. This logic will load Python, create a txtai application instance and add methods to run workflows.

Some assumptions are made:

  • txtai is installed and available

  • A workflow is available in a file named config.yml

  • The workflow only returns the first element

These assumptions are for brevity. This example could be expanded on and built into a more robust, full-fledged library.

While this example is in C, Rust has a well-maintained and popular library for interfacing with Python, PyO3. Interfacing with the Python C API is also possible in Java, JavaScript and Go but not as straighforward.

#include <Python.h>

// Global instances
PyObject *module = NULL, *app = NULL;

/**
 * Create txtai module.
 */
PyObject* txtai() {
    PyObject* module = NULL;
    module = PyImport_ImportModule("txtai.app");
    return module;
}

/**
 * Create txtai application instance.
 */
PyObject* application() {
    PyObject* app = NULL;
    app = PyObject_CallMethod(module, "Application", "z", "config.yml");
    return app;
}

/**
 * Run txtai workflow.
 */
PyObject* run(char** args) {
    PyObject* result = NULL;
    result = PyObject_CallMethod(app, "workflow", "z[z]", args[0], args[1]);
    return result;
}

/**
 * Cleanup Python objects.
 */
void cleanup() {
    // Ensure Python instance exists
    if (Py_IsInitialized()) {
        PyErr_Print();

        Py_CLEAR(app);
        Py_CLEAR(module);

        Py_FinalizeEx();
    }
}

/**
 * Initialize a txtai application and run a workflow.
 */
const char* workflow(char** args) {
    PyObject* result = NULL;

    // Create application instance if it doesn't already exist
    if (!Py_IsInitialized()) {
        // Start Python Interpreter
        Py_Initialize();

        // Create txtai module
        module = txtai();

        // Handle errors
        if (!module) {
            cleanup();
            return NULL;
        }

        // Create txtai application
        app = application();

        // Handle errors
        if (!app) {
            cleanup();
            return NULL;
        }
    }

    // Run workflow
    result = run(args);

    // Handle errors
    if (!result) {
        cleanup();
        return NULL;
    }

    // Get first result
    const char *text = PyUnicode_AsUTF8(PyIter_Next(result));

    // Cleanup result
    Py_CLEAR(result);

    return text;
}

Run txtai workflow in C

Let's now write a C program to run a workflow using command line arguments as input.

#include <stdio.h>

extern char* workflow(char** argv);
extern void cleanup();

/**
 * Run a txtai workflow and print results.
 */
int main(int argc, char** argv) {
    if (argc < 3) {
        printf("Usage: workflow <name> <element>\n");
        return 1;
    }

    // Run workflow using command line arguments
    char* text = workflow(argv + 1);
    if (text) {
        printf("%s\n", text);
    }

    // Cleanup
    cleanup();

    return 0;
}

Compile and run

Time to compile this all into an executable and run!

cc -c main.c -I/usr/include/python3.7m
cc -c workflow.c -I/usr/include/python3.7m
cc -o workflow workflow.o main.o -lpython3.7m
!./workflow translate "I'm running machine translation using a transformers model in C!"
J'exécute la traduction automatique à l'aide d'un modèle de transformateurs en C!

And there it is, a translation workflow from English to French in a native executable, all backed by Transformers models. Any workflow YAML can be loaded and run in C using this method, which is pretty powerful.

Embedding txtai in native executable adds libpython as a dependency (libraries from 3rd party modules such as PyTorch and NumPy also load dynamically). See output of ldd below. This opens up an avenue to embed txtai in native code provided it is acceptable to add libpython as a project dependency.

As mentioned above, connecting to a txtai HTTP API instance is a less tightly coupled way to accomplish the same thing.

ldd workflow | grep python
libpython3.7m.so.1.0 => /usr/lib/x86_64-linux-gnu/libpython3.7m.so.1.0 (0x00007efcba85e000)

Machine learning in Assembly?

Now for a more academic exercise perhaps bringing you back to a computer organization/logic class from college. Let's see if we can run the same program in assembly!

global main

; External C library functions
extern puts

; External txtai functions
extern workflow, cleanup

; Default to REL mode
default REL

section .data
    message:    db  "Usage: workflow <name> <element>", 0

section .text

; Print a usage message
usage:
    mov     rdi, message
    call    puts
    jmp     done

; Main function
main:
    ; Enter
    sub     rsp, 8

    ; Read argc - require workflow name and element (plus program name)
    cmp     rdi, 3
    jl      usage

    ; Run txtai workflow with argv params (skip program name) and print result
    lea     rdi, [rsi + 8]
    call    workflow
    mov     rdi, rax
    call    puts

done:
    ; Close txtai application instance
    call    cleanup

    ; Exit
    add     rsp, 8
    ret
# Build workflow executable
nasm -felf64 main.asm
cc -c workflow.c -I/usr/include/python3.7m
cc -o workflow -no-pie workflow.o main.o -lpython3.7m
./workflow translate "I'm running machine translation using a transformers model with assembler!"
J'exécute la traduction automatique à l'aide d'un modèle de transformateurs avec assembleur!

Just as before, the input text is translated to French using a machine translation model. But this time the code executing the logic was in assembly!

Probably not terribly useful but using the lowest level of code possible proves that any higher-level native code can do the same.

Multiple workflow calls

Everything up to this point has been a single workflow call. Much of the run time is spent on loading models as part of the txtai workflow. The next example will run a series of workflow calls and compare how long it takes vs a single workflow command line call. Once again in assembly.

global main

; External C library functions
extern printf

; External txtai functions
extern workflow, cleanup

; Default to REL mode
default REL

section .data
    format:     db  "action: %s", 10, "input:  %s", 10, "output: %s", 10, 10, 0
    summary:    db  "summary", 0
    translate:  db  "translate", 0
    text1:      db  "txtai executes machine-learning workflows to transform data and build AI-powered semantic search applications.", 0
    text2:      db  "Traditional search systems use keywords to find data", 0
    url1:       db  "https://github.com/neuml/txtai", 0
    url2:       db  "https://github.com/neuml/paperai", 0

section .text

; Run txtai workflow and print results
%macro txtai 2
    ; Workflow name and element
    push    %2
    push    %1

    ; Run workflow
    lea     rdi, [rsp]
    call    workflow

    ; Print action-input-output
    mov     rdi, format
    mov     rsi, [rsp]
    mov     rdx, [rsp + 8]
    mov     rcx, rax
    call    printf

    ; Restore stack
    add     rsp, 16
%endmacro

; Main function
main:
    ; Enter
    sub     rsp, 8

    ; Run workflows
    txtai   translate, text1
    txtai   translate, text2
    txtai   summary, url1
    txtai   summary, url2

done:
    ; Close txtai application instance
    call    cleanup

    ; Exit
    add     rsp, 8
    ret
time ./workflow translate "I'm running machine translation using a transformers model with assembler!"
J'exécute la traduction automatique à l'aide d'un modèle de transformateurs avec assembleur!

real  0m19.208s
user  0m11.256s
sys   0m3.224s
# Build workflow executable
nasm -felf64 main.asm
cc -c workflow.c -I/usr/include/python3.7m
cc -no-pie -o workflow workflow.o main.o -lpython3.7m
time ./workflow
action: translate
input:  txtai executes machine-learning workflows to transform data and build AI-powered semantic search applications.
output: txtai exécute des workflows d'apprentissage automatique pour transformer les données et construire des applications de recherche sémantique alimentées par l'IA.

action: translate
input:  Traditional search systems use keywords to find data
output: Les systèmes de recherche traditionnels utilisent des mots-clés pour trouver des données

action: summary
input:  https://github.com/neuml/txtai
output: txtai executes machine-learning workflows to transform data and build AI-powered semantic search applications. Semantic search applications have an understanding of natural language and identify results that have the same meaning, not necessarily the same keywords. API bindings for JavaScript, Java, Rust and Go. Cloud-native architecture scales out with container orchestration systems (e. g. Kubernetes)

action: summary
input:  https://github.com/neuml/paperai
output: paperai is an AI-powered literature discovery and review engine for medical/scientific papers. Paperai was used to analyze the COVID-19 Open Research Dataset (CORD-19) paperai and NeuML have been recognized in the following articles: Cord-19 Kaggle Challenge Awards Machine-Learning Experts Delve Into 47,000 Papers on Coronavirus Family.


real  0m22.478s
user  0m13.776s
sys   0m3.218s

As we can see, running 4 workflow actions is about the same runtime as a single action when accounting for model load times.

Wrapping up

This article walked through an example on how to run txtai with native code. While the HTTP API is a better route to go, this is another way to work with txtai!
